High-resolution genomic configuration of FGFR rearrangements dictates the therapeutic vulnerability of squamous cell lung cancers

Squamous cell lung cancers (SQCLC) have significant cellular heterogeneity and few therapeutic targets. In the paper by Malchers et al., 8p11-p12 amplifications involving FGFR1, frequently altered in SQCLC, have been examined by high-resolution deep-sequencing (1). The amplification of 8p11-p12 arises from breakage-fusion-bridges (BFB) and its genomic impact can vary with respect to genomic architecture of FGFR1. Of note, the tail-to-tail rearrangements in or close to FGFR1 lead to FGFR1-centered, focal high-level amplifications, which showed responsiveness to FGFR inhibitors in vitro and in vivo, indicative of FGFR dependency. This correlation between the genetic dependency and genomic configurations suggests that the traditional arm- or cytoband-level genomic markers can be elaborated using high-resolution genomic tools to ensure their clinical relevance.

There has been a recent improvement in the survival of patients with SQCLC due to the advent of anti-PD1-based immune checkpoint inhibitors. However, only a limited number of patients benefit from these treatments. Along with few molecular targets approved for the disease, this makes the treatment of SQCLC particularly challenging (2,3). The Cancer Genome Atlas group has provided a comprehensive molecular profiling of 178 early-stage SQCLC tumors in 2012 (4). This study revealed frequently altered somatic changes encompassing multiple biological pathways, e.g., genes with significant amplifications or deletions such as SOX2, FGFR1, WHSC1L1, PGFRA, KIT, CCND1, CDNK2A, NFE2L2, MYC, CDK6, and PTEN along with recurrent mutations in TP53, CDKN2A, PTEN, PIK3CA, KEAP1, HLA-A, MLL2, NFE2L2, NOTCH1, and RB1. Compared to lung adenocarcinomas with well-recognized alterations such as EGFR exon19 del or exon 21-L858R, oncogenic driver mutations are relatively deficit in SQCLC. However, some recurrent alterations such as the amplification of FGFR1 observed in approximately 20% of SQCLC, may be eligible candidates for targeted treatments (5). A variable correlation between gene amplification, mRNA expression, and protein expression of FGFR1 have been reported in cell lines and tumors indicative of heterogeneity in the mechanisms of FGFR amplification and their transcriptional-translation regulation (6). This heterogeneity may contribute to variable response rates to FGFR inhibitors, e.g., not all cells or animal models with FGFR1 amplification respond to FGFR1 inhibitors (5). Of note, a number of FGFR inhibitors, especially small molecule inhibitors such as infigratinib (BGJ398), AZD4547, erdafitinib (JNJ-42756493), have been tested in phase I and II trials, but the overall response rates were 8–15%, and FGFR1 amplification was not particularly meaningful as a predictive biomarker (7-9).

To dissect the heterogeneity in terms of molecular mechanisms of FGFR1 amplification and their impact on the efficacy to FGFR inhibitors, Malchers et al. performed deep sequencing (hybrid capture-based sequencing) on 8p11-p12 amplifications across primary SQCLCs, cancer cell lines and patient-derived xenografts (1). Out of ten primary cases with FGFR1 amplification detected by traditional methods such as fluorescence in situ hybridization (FISH), only four responded to FGFR inhibitors confirming that FGFR1 amplification alone does not serve as predictive markers for FGFR inhibitors. Of note, two patients who showed the sensitivity to FGFR inhibitors, demonstrated unique genomic configurations near the FGFR1 locus. The configurations consisted of the deletion of FGFR1 ectodomain (up to exon 8) and the ‘stair-like’ amplification centered at FGFR1. While the ectodomain deletion indicates the loss of self-inhibitory, immunoglobulin-like domains, the resulting N-terminally truncated FGFR1 still have intact transmembrane and kinase domains with active transcription. These patient-derived N-terminally truncated FGFR1 version were tested in vitro for the FGFR dependency. Moreover, the examination of 8p-amplified cell lines and patient-derived xenografts confirmed that those with FGFR dependency typically display FGFR1-centered amplicons, that pattern of which can be detected by relatively low-resolution copy number profiles encompassing FGFR1 locus. The second notable feature associated with FGFR1 dependency is the ‘stair-like’ amplification at FGFR1 locus, which is a typical feature of BFB recursive cycles. Moreover, tail-to-tail rearrangements at or close in the FGFR1 were associated with the FGFR1-centered amplifications and potentially with FGFR dependency. Overall, tail-to-tail rearrangements in or close to FGFR1 were observed in 78% of the observed responders (7 out of 9) while only 25% of non-responders (3 out of 12) showed the tail-to-tail rearrangements suggesting the tail-to-tail rearrangements as the distinguishing features of FGFR1 dependency.

BFB has been first proposed by Barbara McClintock in maize as a mechanism of chromosomal instability (10). BFB cycles begin with telomere loss (breakage) followed by the formation of a dicentric chromosome (fusion) and subsequent breakage at bridge-like structure. These steps can iterate repeatedly as BFB cycle. BFB cycles can generate complex chromosomal rearrangements and amplifications often responsible for copy number gains of oncogenes in cancer genomes (11). BFB cycles are often associated with chromothripsis, a catastrophic genomic event where multiple chromosomal breakages occur simultaneously and reassemble randomly, creating a complex mixture of chromosomal segments (12). The association of BFB cycles and chromothripsis suggests a mechanistic connection thereby contributing to pronounced genomic instability of cancer genomes (13). Moreover, the extensive BFB cycles often generate the extrachromosomal DNAs instead of creating homogeneously staining regions in cis (14). While reports have highlighted oncogene amplifications through BFB cycles, the impact of their resulting genomic configurations, especially in clinical contexts, remains largely unexplored.

In summary, the tail-to-tail rearrangement at or close to FGFR1 leading to the FGFR1-centered amplifications, indicate the FGFR1 dependency with the sensitivity to FGFR inhibitors. The unique genomic characteristics, marked by copy number profiles with peaks at or near the FGFR1 locus, are identifiable across a range of DNA sequencing platforms, including panel sequencing (those covering FGFR1 locus) and whole genome sequencing. This adaptability makes this biomarker a viable option for incorporation into current clinical practices. The challenge remains due to the limited performance in predicting the FGFR1 dependency (sensitivity =77.8% and specificity =75%, respectively, on pooled data including cell lines, xenograft models and patients of the report) (1). One possible explanation for this genotype-phenotype discordance may be the genomic heterogeneity, where the BFB cycles frequently gives multiple subclones with different copy number states (11). Another challenge is to discover the roles FGFR1 amplification accompanying features, such as the deletion of NSD3 adjacent to FGFR1, which co-occurs with FGFR1 amplifications, or exclusive genomic alterations such as PIK3CA mutations enriched in genomes non-responsive to FGFR inhibitors. While Malchers et al. primarily examined the genetic structure of coding sequences related to FGFR1, there is a possibility that epigenetic abnormalities linked to chromosomal rearrangements affect the drug response. For instance, in cancer genomes, structural variations often result in enhancers being placed next to key driver genes (a process known as ‘enhancer hijacking’), which leads to transcriptional upregulation of cancer driver genes (15). One interesting phenomenon is that FGFR1 expression is more concordant with protein levels than FGFR1 copy numbers suggesting that roles of epigenetics need to be further investigated (16). Moreover, the amplification of 8p11.12, which involves FGFR1 and additional genes such as ZNF703, ERLIN2, PLPBP, ADGRA2, BRF2, RAB11FIP1, GOT1L1, ADRB3, EIF4EBP1, ASH2L, STAT, LSM1, BAG4, DDHD2, PLPP5, NSD3, LETM2, and TACC1, is commonly observed in various tumor types, including breast, esophageal, and bladder cancers (17,18). Although FGFR1 inhibitors have shown promising responses in some tumor types (19), further research is needed to understand the detailed genomic structure of 8q11.12 and the potential influence of other neighboring genes in different types of tumors. The accompanying commentary on the article by Mäkinen and Meyerson are also available for further insights (20).

It is also of note that the Malchers et al. highlighted high-resolution genome features that can significantly benefit from whole genome sequencing (1). Despite the cost of whole genome sequencing remaining stable since 2015, recent advancements in sequencing technology and artificial intelligence-driven data processing have reduced it to around 200 USD recently (21). The price is anticipated to drop further as patents on key sequencing technologies expire. The reduction in sequencing costs may benefit cancer genome sequencing by expanding eligibility for whole-genome sequencing, which provides detailed insights into characteristics associated with structural variations and chromosomal rearrangements. With the anticipated drop in the cost of whole genome sequencing to around 100 USD, we expect resurgence in investigating traditional genetic markers, paving the way for next-level precision medicine.

Acknowledgments

Funding: None.

Footnote

Provenance and Peer Review: This article was commissioned by the editorial office, Translational Lung Cancer Research. The article has undergone external peer review.

Peer Review File: Available at https://tlcr.amegroups.com/article/view/10.21037/tlcr-23-705/prf

Conflicts of Interest: Both authors have completed the ICMJE uniform disclosure form (available at https://tlcr.amegroups.com/article/view/10.21037/tlcr-23-705/coif). The authors have no conflicts of interest to declare.

Ethical Statement: The authors are accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved.

Open Access Statement: This is an Open Access article distributed in accordance with the Creative Commons Attribution-NonCommercial-NoDerivs 4.0 International License (CC BY-NC-ND 4.0), which permits the non-commercial replication and distribution of the article with the strict proviso that no changes or edits are made and the original work is properly cited (including links to both the formal publication through the relevant DOI and the license). See: https://creativecommons.org/licenses/by-nc-nd/4.0/.

References

1. Malchers F, Nogova L, van Attekum MH, et al. Somatic rearrangements causing oncogenic ectodomain deletions of FGFR1 in squamous cell lung cancer. J Clin Invest 2023;133:e170217. [Crossref] [PubMed]
2. Lau SCM, Pan Y, Velcheti V, et al. Squamous cell lung cancer: Current landscape and future therapeutic options. Cancer Cell 2022;40:1279-93. [Crossref] [PubMed]
3. Novello S, Kowalski DM, Luft A, et al. Pembrolizumab Plus Chemotherapy in Squamous Non-Small-Cell Lung Cancer: 5-Year Update of the Phase III KEYNOTE-407 Study. J Clin Oncol 2023;41:1999-2006. [Crossref] [PubMed]
4. Comprehensive genomic characterization of squamous cell lung cancers. Nature 2012;489:519-25. [Crossref] [PubMed]
5. Wynes MW, Hinz TK, Gao D, et al. FGFR1 mRNA and protein expression, not gene copy number, predict FGFR TKI sensitivity across all lung cancer histologies. Clin Cancer Res 2014;20:3299-309. [Crossref] [PubMed]
6. Weiss J, Sos ML, Seidel D, et al. Frequent and focal FGFR1 amplification associates with therapeutically tractable FGFR1 dependency in squamous cell lung cancer. Sci Transl Med 2010;2:62ra93. [Crossref] [PubMed]
7. Paik PK, Shen R, Berger MF, et al. A Phase Ib Open-Label Multicenter Study of AZD4547 in Patients with Advanced Squamous Cell Lung Cancers. Clin Cancer Res 2017;23:5366-73. [Crossref] [PubMed]
8. Nogova L, Sequist LV, Perez Garcia JM, et al. Evaluation of BGJ398, a Fibroblast Growth Factor Receptor 1-3 Kinase Inhibitor, in Patients With Advanced Solid Tumors Harboring Genetic Alterations in Fibroblast Growth Factor Receptors: Results of a Global Phase I, Dose-Escalation and Dose-Expansion Study. J Clin Oncol 2017;35:157-65. [Crossref] [PubMed]
9. Tabernero J, Bahleda R, Dienstmann R, et al. Phase I Dose-Escalation Study of JNJ-42756493, an Oral Pan-Fibroblast Growth Factor Receptor Inhibitor, in Patients With Advanced Solid Tumors. J Clin Oncol 2015;33:3401-8. [Crossref] [PubMed]
10. McClintock B. The Stability of Broken Ends of Chromosomes in Zea Mays. Genetics 1941;26:234-82. [Crossref] [PubMed]
11. Toledo F. Mechanisms Generating Cancer Genome Complexity: Back to the Future. Cancers (Basel) 2020;12:3783. [Crossref] [PubMed]
12. Stephens PJ, Greenman CD, Fu B, et al. Massive genomic rearrangement acquired in a single catastrophic event during cancer development. Cell 2011;144:27-40. [Crossref] [PubMed]
13. Umbreit NT, Zhang CZ, Lynch LD, et al. Mechanisms generating cancer genome complexity from a single cell division error. Science 2020;368:eaba0712. [Crossref] [PubMed]
14. Kim H, Nguyen NP, Turner K, et al. Extrachromosomal DNA is associated with oncogene amplification and poor outcome across multiple cancers. Nat Genet 2020;52:891-7. [Crossref] [PubMed]
15. Weischenfeldt J, Dubash T, Drainas AP, et al. Pan-cancer analysis of somatic copy-number alterations implicates IRS4 and IGF2 in enhancer hijacking. Nat Genet 2017;49:65-74. [Crossref] [PubMed]
16. Bogatyrova O, Mattsson JSM, Ross EM, et al. FGFR1 overexpression in non-small cell lung cancer is mediated by genetic and epigenetic mechanisms and is a determinant of FGFR1 inhibitor response. Eur J Cancer 2021;151:136-49. [Crossref] [PubMed]
17. Voutsadakis IA. Amplification of 8p11.23 in cancers and the role of amplicon genes. Life Sci 2021;264:118729. [Crossref] [PubMed]
18. Voutsadakis IA. Characteristics and Prognosis of 8p11.23-Amplified Squamous Lung Carcinomas. J Clin Med 2023;12:1711. [Crossref] [PubMed]
19. Loriot Y, Necchi A, Park SH, et al. Erdafitinib in Locally Advanced or Metastatic Urothelial Carcinoma. N Engl J Med 2019;381:338-48. [Crossref] [PubMed]
20. Mäkinen N, Meyerson M. Genomic insights into the mechanisms of FGFR1 dependency in squamous cell lung cancer. J Clin Invest 2023;133:e174171. [Crossref] [PubMed]
21. Eisenstein M. Innovative technologies crowd the short-read sequencing market. Nature 2023;614:798-800. [Crossref] [PubMed]
